Enclosure Type Bass reflex
Transducer Complement 3-way
Bass Driver 8"(200mm) black woven Kevlar® cone
Midrange Driver 5"(135mm) black woven Kevlar® cone
Treble Driver 1" (25mm) soft dome
AV Shield No
Sensitivity (2.83v @1m) 90dB
Recommended Amplifier Power 25-200W
Peak SPL 110dB
Nominal Impedance 6Ω
Minimum Impedance 3.5Ω
Frequency Response(+/-3dB) 40Hz ~ 20kHz
Bass Extension(-6dB) 35Hz
Crossover Frequency 630Hz & 2.4kHz
Height (on plinth) 565mm
Width 300mm
Depth (with terminals) (330+30)mm
