Amplifier Section
Power Output
All Channels
Dynamic Power
100 W/Ch (6 Ω, 1 kHz, 1% THD, 1 Channel Driven, IEC)
100 W/Ch (6 Ω,1 kHz, 1% THD, 1 Channel Driven, JEITA)
160 W (3 Ω, Front) 125 W (4 Ω, Front) 85 W (8 Ω, Front)
THD+N (Total Harmonic Distortion + Noise)
0.08% (20 Hz–20 kHz, Half Power) Damping Factor Over 40 (Front, 1 kHz, 8 Ω)
Input Sensitivity and Impedance
200 mV/47 kΩ (Line)
Frequency Response Tone Control
1V /470 Ω (Subwoofer Pre Out)
10 Hz–100 kHz/+1 dB, -3 dB (Direct Mode)
±10 dB, 20 Hz (Bass) ±10 dB, 20 kHz (Treble)
      Signal-to-Noise Ratio 100 dB (Line, IHF-A)
Speaker Impedance 6Ω–16Ω
Dimensions (W x H x D) : 435 x 160 x 328 mm
Supplied Accessories
• Indoor FM antenna • AM loop antenna
• Speaker setup microphone • Instruction manual • Remote controller • AA (R6) batteries x 2
